Canon EF-S 17-85mm f/4-5.6 IS USM Chromatic Aberration / Linear Distortion
Methods used to determine chromatic aberration are here. Mild chromatic aberration was observed in the outer 39% area of the image field. Moderate chromatic aberration was observed in the outer 61% area of the image field at 55mm with the EF-S 18-55mm lens. To see chromatic aberration in download examples, download the files, open them in Photoshop and display edges of images at 200%. The examples are crops of full-size, large fine jpg's out of the 20D or EOS-1D. Linear distortion was also reported from the images. (Note: Uncropped examples were originally posted. Cropped sections had to be substituted because of high band width demands on the site.)
Focal length for EF 28-135mm f/3.5-5.6 IS and EOS-1Ds (full frame) |
Focal length for EF-S 17-85mm f/4-5.6 IS and EF-S 18-55mm f/3.5-5.6 and 20D (APS-C) |
EF-S 17-85mm f/4-5.6 IS @ f/8 20D Chromatic aberration (CA) and linear distortion |
EF 28-135mm f/3.5-5.6 IS @ f/8 EOS-1Ds Chromatic aberration (CA) and linear distortion |
EF-S 18-55mm f/3.5-5.6 @ f/8 20D Chromatic aberration (CA) and linear distortion |
28mm | 17 or 18mm | mild CA moderate barrel dist. |
mild CA moderate barrel dist. |
no CA moderate barrel dist. |
33mm | 22mm | mild CA (example) minimal pin cushion dist. |
mild CA (example) mild barrel dist. |
no CA minimal barrel dist. |
50mm | 33mm | mild CA mild pin cushion dist. |
mild CA mild pin cushion dist. |
no CA negligible dist. |
85mm | 53 or 55mm | negligible CA mild pin cushion dist. |
negligible CA mild pin cushion dist. |
moderate CA (example) minimal pin cushion dist. |
135mm | 85mm | no CA mild pin cushion dist. |
no CA moderate pin cushion dist. |
20D / EF-S Lens Report Index Page
©
2004, William L. Castleman
Posted 9
October 2004, Revised 18 October 2004
